CF Moto Jetmax 250的代码为 806A-150900
This is CF250 Jetmax 250 Fuel Pump Assembly, total length is about 24cm.
This fuel pump assembly includes fuel pump, plastic support, preliminary filter, fine filter and pressure regulator. It supplies fuel for engine under a certain pressure and flow.
This fuel pump is located in fuel tank.
- Don't operate the fuel pump in dry condition in order to prevent damage.
- Always handle the fuel pump gently.
- Never drop the fuel pump, especially on a hard surface.
- Battery supplies power for fuel pump assembly via fuel pump relay, which connects the fuel pump circuit only with the engine started.
Fuel pressure test:
- Connect the fuel pressure gauge with fuel outlet and tighten the joint with a clamp to prevent fuel leaks.
- Route according to the right circuit.
- Turn both ignition switch engine stop switch on.
- At this moment, fuel pump will operate for 5 seconds. After the fuel pump stops running, fuel pressure should be in specification. Otherwise, replace it.
- After the engine stops running,0.25MPa fuel pressure should be kept for more than 5 minutes. Otherwise, replace the fuel pump.
- 请确认该零件适用于您的具体车型及年份。同一名称的车可能因生产年份不同而使用不同零件。
- 建议购买前核对车辆手册，或联系客服确认兼容性。
- 图片、尺寸和描述仅供参考。因生产批次或拍摄光线，实物可能存在细微差异。
- 您收到的商品在功能上符合描述，但外观可能有轻微不同。
- 运费和税费不包含在内。 买家自行承担所有额外费用。
感谢您的推荐
请将我们的产品推荐给你的朋友 燃油泵总成 24cm
