金浪150曲轴 F150
- 品牌： Mortch Motor
- 型号： MIGY150-3013B
- 浏览： 7
- 库存： 现货商品
- 重量： 3.50kg
- 尺寸： 13.00 x 13.00 x 29.00cm
¥120.00
| 运往： |
A replacement crankshaft in standard OEM quality for 125cc/150cc 4 stroke QJ153MI engines, you may can find from Jinlang, or other model with 157M engine. This crankshaft with 6305(62mm) and 63/22 P5(56mm) bearing.
- Threads: 12mm
- Thread Length: 14mm
- Wrist pin inner diameter: 15mm
- Overall Length: 286mm
- Number of Splines: 19
- Number of Gear: 17T (both side)
- 请确认该零件适用于您的具体车型及年份。同一名称的车可能因生产年份不同而使用不同零件。
- 建议购买前核对车辆手册，或联系客服确认兼容性。
- 图片、尺寸和描述仅供参考。因生产批次或拍摄光线，实物可能存在细微差异。
- 您收到的商品在功能上符合描述，但外观可能有轻微不同。
- 运费和税费不包含在内。 买家自行承担所有额外费用。
