Z8/Z1000燃油泵总成

CF Moto的代码为7000-150900

This fuel pump assembly includes fuel pump, plastic support, preliminary filter, fine filter and pressure regulator. It supplies fuel for engine under a certain pressure and flow.
This fuel pump is located in fuel tank.

• Don't operate the fuel pump in dry condition in order to prevent damage.
• Always handle the fuel pump gently.
• Never drop the fuel pump, especially on a hard surface.
• Battery supplies power for fuel pump assembly via fuel pump relay, which connects the fuel pump circuit only with the engine started.

Fuel pressure test:

• Connect the fuel pressure gauge with fuel outlet and tighten the joint with a clamp to prevent fuel leaks.
• Route according to the right circuit.
• Turn both ignition switch engine stop switch on.
• At this moment, fuel pump will operate for 5 seconds. After the fuel pump stops running, fuel pressure should be in specification. Otherwise, replace it.
• After the engine stops running,0.25MPa fuel pressure should be kept for more than 5 minutes. Otherwise, replace the fuel pump.

本商品可适用于

• POLICE MOTORCYCLE  2022  CF800(Z8)  ZForce 800EX
• SSV  2016  CF1000US-2  ZForce 1000
• SSV  2017  CF1000US-2  ZForce 1000
• SSV  2018  CF1000US-2  ZForce 1000
• SSV  2019  CF1000US-2  ZForce 1000
• SSV  2020  CF1000US-2  ZForce 1000
• SSV  2021  CF1000US-2  ZForce 1000
• SSV  2020  CF1000US-2(CA)  ZForce 1000
• SSV  2021  CF1000US-2(CA)  ZForce 1000
• SSV  2019  CF1000US-2(US)  ZForce 1000
• SSV  2017  CF1000UTR-2  ZForce 1000
• SSV  2018  CF1000UTR-2  ZForce 1000
• SSV  2019  CF1000UTR-2  ZForce 1000
• SSV  2020  CF1000UTR-2  ZForce 1000
• SSV  2021  CF1000UTR-2  ZForce 1000
• SSV  2021  CF1000UTR-2(GD)  ZForce 1000
• SSV  2012  CF800  ZForce 800EX
• SSV  2013  CF800  ZForce 800EX
• SSV  2014  CF800  ZForce 800EX
• SSV  2015  CF800  ZForce 800EX
• SSV  2016  CF800  ZForce 800EX
• SSV  2017  CF800  ZForce 800EX
• SSV  2018  CF800  ZForce 800EX
• SSV  2019  CF800  ZForce 800EX
• SSV  2020  CF800  ZForce 800EX
• SSV  2021  CF800  ZForce 800EX
• SSV  2022  CF800  ZForce 800EX
• SSV  2020  CF800(CA)  ZForce 800EX
• SSV  2021  CF800(CA)  ZForce 800EX
• SSV  2022  CF800(CA)  ZForce 800EX
• SSV  2019  CF800(US)  ZForce 800EX
• SSV  2020  CF800(US)  ZForce 800EX
• SSV  2021  CF800(US)  ZForce 800EX
• SSV  2022  CF800(US)  ZForce 800EX
• SSV  2013  CF800US-A  ZForce 800 Trail
• SSV  2014  CF800US-A  ZForce 800 Trail
• SSV  2015  CF800US-A  ZForce 800 Trail
• SSV  2016  CF800US-A  ZForce 800 Trail
• SSV  2017  CF800US-A  ZForce 800 Trail
• SSV  2018  CF800US-A  ZForce 800 Trail
• SSV  2019  CF800US-A  ZForce 800 Trail
• SSV  2020  CF800US-A  ZForce 800 Trail
• SSV  2021  CF800US-A  ZForce 800 Trail
• SSV  2022  CF800US-A  ZForce 800 Trail
• SSV  2020  CF800US-A(CA)  ZForce 800 Trail
• SSV  2021  CF800US-A(CA)  ZForce 800 Trail
• SSV  2022  CF800US-A(CA)  ZForce 800 Trail
• SSV  2019  CF800US-A(US)  ZForce 800 Trail
• SSV  2020  CF800US-A(US)  ZForce 800 Trail
• SSV  2021  CF800US-A(US)  ZForce 800 Trail
• SSV  2022  CF800US-A(US)  ZForce 800 Trail
• SSV  2017  CF800UTR  ZForce Z8-EX
• SSV  2018  CF800UTR  ZForce Z8-EX
• SSV  2019  CF800UTR  ZForce Z8-EX
• SSV  2020  CF800UTR  ZForce Z8-EX
