燃油泵总成 20cm

CF Moto的代码为901F-150900-10000 替换代码901F-15.09.00

• Total length about 20cm

This fuel pump assembly includes fuel pump, plastic support, preliminary filter, fine filter and pressure regulator. It supplies fuel for engine under a certain pressure and flow.
This fuel pump is located in fuel tank.

• Don't operate the fuel pump in dry condition in order to prevent damage.
• Always handle the fuel pump gently.
• Never drop the fuel pump, especially on a hard surface.
• Battery supplies power for fuel pump assembly via fuel pump relay, which connects the fuel pump circuit only with the engine started.

Fuel pressure test:

• Connect the fuel pressure gauge with fuel outlet and tighten the joint with a clamp to prevent fuel leaks.
• Route according to the right circuit.
• Turn both ignition switch engine stop switch on.
• At this moment, fuel pump will operate for 5 seconds. After the fuel pump stops running, fuel pressure should be in specification. Otherwise, replace it.
• After the engine stops running,0.25MPa fuel pressure should be kept for more than 5 minutes. Otherwise, replace the fuel pump.

本商品可适用于

• ATV  CF400ATR  CForce 450
• ATV  CF400ATR-2L(T3a)  CForce 450L
• ATV  CF400ATR-2L(T3b)  CForce 450L
• ATV  CF400ATR-2S(T3a)  CForce 450S
• ATV  CF400ATR-2S(T3b)  CForce 450S
• ATV  CF400ATR-4L  GOES TERROX 400L
• ATV  CF400ATR-4S  GOES TERROX 400S
• ATV  CF400ATR-5L(T3b)  IRON MAX T3
• ATV  CF400ATR-5S(T3b)  IRON T3
• ATV  CF400ATR-L  CForce 450L
• ATV  CF400AU  CForce 400S/450S
• ATV  CF400AU-2L  IRON MAX L7e
• ATV  CF400AU-2S  IRON L7e
• ATV  CF400AU-A  CForce 450S
• ATV  CF400AU-B  CForce 450L
• ATV  CF400AU-G  GOES TERROX 400S
• ATV  CF400AU-L  CForce 400L/450L
• ATV  CF400AU-LA  GOES TERROX 400L
• ATV  CF500-5B  X5
• ATV  CF500-5C  X5
• ATV  CF500ATR  CForce 520
• ATV  CF500ATR-11L  GOES TERROX 500L
• ATV  CF500ATR-11S  GOES TERROX 500S
• ATV  CF500ATR-2L(T3a)  CForce 520L
• ATV  CF500ATR-2L(T3b)  CForce 520L
• ATV  CF500ATR-2S(T3a)  CForce 520S
• ATV  CF500ATR-2S(T3b)  CForce 520S
• ATV  CF500ATR-3  CForce 520
• ATV  CF500ATR-3(T3a)  CForce 520
• ATV  CF500ATR-5L(T3b)  COBALT MAX T3
• ATV  CF500ATR-5S(T3b)  COBALT T3
• ATV  CF500ATR-A  CForce 550
• ATV  CF500AU-6B  CForce 550
• ATV  CF500AU-6L  CForce 550
• ATV  CF500AU-7A  CForce 520S
• ATV  CF500AU-7C  CForce 520L
• ATV  CF500AU-7L  CForce 520L
• ATV  CF500AU-7LA  GOES TERROX 500L
• ATV  CF500AU-7LF  CForce 520L
• ATV  CF500AU-7S  CForce 520 S
• ATV  CF500AU-7SA  GOES TERROX 500S
• ATV  CF500AU-7SF  CForce 500S/CForce 520S
• ATV  CF500AU-8L  COBALT MAX L7e
• ATV  CF500AU-8S  COBALT L7e
• ATV  CF500-E  X5
• ATV  CF600ATR-2L(T3b)  CForce 625 Touring
• ATV  CF600ATR-2S(T3b)  CForce 625
• ATV  CF600ATR-L(T3a)  CForce 600
• ATV  CF600ATR-L(T3b)  CForce 600
• ATV  CF600AU-3L  CForce 600 Touring/625 Touring
• ATV  CF600AU-3S  CForce 600/625
• ATV  CF600AU-L(EU168)  CForce 600
• ATV  CF600AU-L(INTERNATIONAL)  CForce 600
• ATV  CF600AU-L  CForce 600 EPS
• ATV  CF600AZ-3L  CForce 600
• ATV  CF600AZ-3S  CForce 600
• ATV  CF600-B  X6
• ATV  CF600-C  X6
• ATV  CF625-2  X6
• ATV  CF625-2A  X6
• ATV  CF625-B  X6
• ATV  CF625-C  X6
