Natty Front Brake System
- Brand: Mortch Motor
- Product Code: MIBRS-NATTY
- Product Viewed: 8
- Availability: Pre-Order
- Weight: 1.92kg
- Packing Size: 7.00 x 8.00 x 7.00cm
¥130.02
| Shipping To： |
Supported with the items of: Natty A Scooter, Natty B Scooter, Natty C Scooter, Natty D Scooter, etc.
| Features : | |
| Operation pressure:6.9MPa Overall pump diameter:ф12.7mm By-pass pump diameter:2-ф25mm Mounting position:Front brake(Lift) Mounting-plate hole space:68mm Length of oil pipe:930mm Theory braking moment:420.N.m |
O.D:ф189mm L.D:ф58mm Thickness:3.5mm No.of holes:3 Mounting parameters: Hole space:ф80mm Aperture:ф10.5mm Parallel height of bottom:3.5mm Valid radius of braking:83mm |
QTY in Box: 15PCs/CTN
- Please verify that this parts fits your specific vehicle model and year. Many vehicle share the same name but may use different parts depending on the manufacturing year.
- We strongly recommend cross-checking with your vehicle's manual or contacting us for confirmation before purchasing.
- Photos, measurements, and descriptions are for reference only. Minor variations may exist due to manufacturing batches or lighting conditions.
- The actual product you receive may differ slightly in appearance but will match the functional specifications.
- Prices listed do NOT include import duties, taxes, or customs clearance fees.
- Buyers are fully responsible for any additional charges imposed by their local customs.
Thank You
Please tell your friends about our Natty Front Brake System
