Rear Drive Shaft Assy

Brand: Mortch Motor
Product Code: MICF9AWV-300110-8000

Product Viewed: 1

Availability: In Stock

Weight: 1.21kg

0 reviews / Write a review

¥204.00

Shipping To：

More Quotes

🔧 CFMoto Rear Drive Shaft Assembly

📦 Part Number: 9AWV-300110-8000

⚙️ Rear Drive Shaft Assy · Rear Propeller Shaft Core · OEM Spec

📍 Installation Location: Rear drivetrain / Inside rear drive shaft assembly

✅ Single unit · High-strength alloy steel · Direct fit · Compatible with multiple CFMoto ATV models

📋 Product Overview

This is a CFMoto OEM-spec Rear Drive Shaft Assembly, part number 9AWV-300110-8000, sold as a single unit. This core shaft assembly is the central component of the rear drive shaft assembly, consisting of the core shaft welded to yoke or spline components with precision welding. Installed inside the rear drive shaft, it transfers power from the transmission to the rear axle — a critical load-bearing component in the 4WD rear driveline.

Over time, the original core shaft assembly may suffer from weld fatigue, twisting deformation, spline wear, or universal joint wear under high loads and rough terrain — leading to rear drive shaft vibration, noise, or even failure. Replacing with an OEM-spec core shaft assembly is essential to restore rear driveline reliability and safety.

✅ OEM Quality Assurance: Manufactured strictly to CFMoto original technical standards. Made from high-strength alloy steel, with welding quality and dimensional precision identical to the genuine part, ensuring a perfect replacement and reliable power transfer performance.

📐 Specifications

🔖 Part Number: 9AWV-300110-8000

🏷️ Product Name: Rear Drive Shaft Assembly

📦 Packaging: Single unit

📍 Installation: Inside rear drive shaft assembly

🧪 Material: High-strength alloy steel (welded assembly)

⚙️ Function: Transfer power to rear wheels · Connect universal joints

🚗 Vehicle Compatibility

This Rear Drive Shaft Assembly (part number 9AWV-300110-8000, single unit) fits the following CFMoto ATV models:

🏍️ 1000cc Series

2024-2026 CF1000ATR-2 · CForce 1000 X10
2025-2026 CF1000ATR-2A · CForce 1000 X10 Overland
2025-2026 CF1000ATR-3 · CForce 1000 MUD
2025-2026 CF1000ATR-3L · CForce 1000 MV
2026 CF1000ATR-4L · GOES TERROX 1000 T3b
2025-2026 CF1000AU-2 · CForce 1000 X10 Overland
2026 CF1000AU-4L · GOES TERROX 1000 EPS
2024-2025 CF1000AZ-2 · CForce 1000 Touring
2025 CF1000AZ-2A · CForce 1000 Overland

🏍️ 800cc Series

2024-2026 CF800ATR-5 · CForce 850 X8 Touring
2025-2026 CF800AU-3 · CForce 850 X8 Touring
2024-2025 CF800AZ-3 · CForce 800 Touring / CForce 850 Touring

📌 Fitment Note: This rear drive shaft assembly fits the rear drive shaft assembly of the listed CFMoto ATV models. Sold as a single unit. If your specific model is not listed, please contact us with your VIN to confirm compatibility.

⚙️ Product Features

✅ OEM Original Spec: Manufactured to CFMoto original technical standards; dimensions, spline specs, and welding quality match the genuine part exactly.
🛡️ High-Strength Alloy Steel: Made from premium alloy steel with heat treatment for excellent torsional strength and fatigue resistance.
🔧 Precision Welding: Core shaft and yoke components are precision-welded for structural strength and concentricity.
💪 Direct Fitment: Direct replacement for the original part — no modifications required.
🔄 Direct Replacement: Replaces deformed, worn, or damaged original core shaft assemblies.

✅ Typical signs you need to replace the Rear Drive Shaft Assembly:
• Vibration from the rear drive shaft, especially at highway speeds.
• Unusual noise from the rear drivetrain (metal grinding or knocking).
• Hesitation or jerking at the rear during acceleration or deceleration.
• Visible bending, twisting, or cracks on the core shaft (visual inspection).
• Severe spline or yoke wear with excessive clearance.
If any of these occur, inspect and replace the core shaft assembly promptly to prevent further rear drivetrain damage.

✅ Installation Tips:
1. Confirm the assembly is the correct 9AWV-300110-8000 matching the original.
2. Raise the vehicle with proper support and remove the rear drive shaft assembly.
3. Remove the old core shaft assembly, noting the installation sequence and orientation of components.
4. Clean the shaft bore and mating surfaces, inspecting bearings and seals.
5. Install the new core shaft assembly in the correct orientation.
6. Install universal joints and spline connections, ensuring proper engagement.
7. Torque all fasteners to OEM specifications.
8. Reinstall the rear drive shaft assembly and perform a road test to confirm no noise or vibration.
Installation requires professional lifting equipment and mechanical skill; professional installation recommended.

⚠️ Important Note: This product is a CFMoto Rear Drive Shaft Assembly, part number 9AWV-300110-8000, sold as a single unit. Fits the listed CFMoto ATV models. Slight variations may occur between production batches. If your specific model is not listed, please contact us with your VIN to confirm compatibility. Images are for reference only; actual product may vary. Ensure welded areas are free from damage and torque all bolts to OEM specifications during installation.
